Seasonings Box 1 Cavity NAK80 S136 Overmold Injection Mold

Seasonings Box 1 Cavity NAK80 S136 Overmold Injection Mold

  • Seasonings Box 1 Cavity NAK80 S136 Overmold Injection Mold
  • Seasonings Box 1 Cavity NAK80 S136 Overmold Injection Mold
  • Seasonings Box 1 Cavity NAK80 S136 Overmold Injection Mold
Seasonings Box 1 Cavity NAK80 S136 Overmold Injection Mold
Product Details:
Place of Origin: China
Brand Name: KYE
Certification: ISO9001:ISO14001
Model Number: OEM
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: To Be Negotiation
Packaging Details: Wooden Case With Steel Frame
Delivery Time: 30 working days
Payment Terms: T/T
Supply Ability: 50 Sets Mould Per Month
Contact Now
Detailed Product Description
Mateiral: PA +35% GF With Steelness Thread/Screw Insert Mold Type: 2 Plate-mold
Mold Material: S136, NAK80/S136, NAK80, 718H Mold Base Material: DME, S50C, LKM, LKM & HASCO & DME, HASCO, LKM Mould Base
Cavity Number: 1*1 Cavity Mold Life: 500,000 Shots
High Light:

S136 Overmold Injection Mold

,

NAK80 Overmold Injection Mold

,

1 Cavity Overmold

Seasonings Box 1 Cavity NAK80 S136 Overmold Injection Mold



Overmold tooling is classified as insert molding.
To help identify the difference in the two types of molding, think of injection molding as discrete components molded within a closed mold and insert molding as molding around an item inserted into the mold. During the insert molding process, the goal is to completely fill the mold cavity so that the cosmetic and functional requirements of the finished part are met, but at the same time not cause any uncontrolled molding material to exit the cavity and cause damage to the connector or cable inserted into the mold.



KYE has a team of professional engineer for the product design with full design experience and skill.



What KYE can offer

1. Plasting/die-casting molding



2. Engineering/ Technical

Design for Manufacturing

Mold flow analysis

Mold design

Supplier Managed Inventory

Project management



3. Technical Injection Molding

Robotic and Automated Pick and Place

High Pressure Thin wall

Small Precision and Large Cosmetic

Structural Foam



4. Mold Building

Hot-Runner Capability

Assembly Fixtures

Complex Surfaces

Mold up range from samll, middle and large







Product Details Description

A/B plate steel P20
Mould type 2 plate-mould
Mould base steel LKM Mould Base, DME, S50C LKM,LKM & HASCO & DME, HASCO,
Mould standard DME
Core/Caviry steel 718H, S136, NAK80/S136, NAK80,
Runner type Cold runner
Mould number According to customer requirement
Cycle time 65s
Design software CAD, UG, Proe
MOQ 1 set
Payment term T/T
Package Artificial wooden box
Mould life 0.5 million shots
Gate type edge gate
Deliverly date 4-5 Weeks



Seasonings Box 1 Cavity NAK80 S136 Overmold Injection Mold 0

Our Advantage

1. Injection molding workshop

KYE has around 40-50 sets of injection machine range from 50T to 600T.



2. Professional Engineer team

KYE has 6-8 engineers with 10~15 year of full expereience, their professional skill can offer you the best solution for the project and help you manage the project in the best effective way.



3. Thorough project management system

KYE has thorough project management system from sales team to engineer and worker team.



4. Owned mold making workshop

KYE has owned mold workshop with 2000 squre meteres in house to make sure the high quality and lead time.



5. Various Service

We offer various service including Automotive parts, Home Appliance, Electronic and Medical parts with one stop service

including product design, mould fabrication and second processing, such as Spray painting, Printing, Chrome, Engrave and assembling,etc.



KYE can offer fast mold and part quote (inserts must be quoted offline by a project manager), Low cost, quick build and high quality, Mold frame sharing technology, Online project management

1. Electronic product mold
Digital Signal Processor Cover, Plastic Lampholder, Plastic Lamp Shade, Socket Cover, Enclosure Cover, Semi-transparent Lamp Shade, Electronic Product Shell, Heating Panel, Intelligent Touch-screen Cover and Base



2. Home appliance product mold

Kitchen Appliances, Coffee port cover, Baby Plastic Tray Covers, Home appliance component, Plastic Spoon, Plastic Filter Shim, Home appliance component, Bottle Cap



3. Automotive mold

Automotive trim, Rearview mirror shell, Central glive box, Front and rear wheel brow, Door frame,Roof rack,Before and after the retaining bar
Round shel cover plate, front and rear pedal, Air outlet grille, Auto lamp,The front baffle, Cockpit, Plastic Spindle



4. Over-mould injection mold

Bi-color cap, remote control mold, Hand Grip/hold/knob/shank,Road Traffic Cones Base,Cosmetic Bi Color Fliptop Cap,Bi-color Screen Frame,Medical product hand Grip



5. Die casting mold

Camera Chassis,Radio Assembly for Satellite Systems,Camera Housing,Cartridge Adhesive Applicators,Tablet Frame,toothbrush base and shaft, heat sink for LED headlinghts, phone front cover,Aluminum Heat Sink Cover,Aluminum Motor Cover



6. Industrial product mold

Insert molding,Plug Lid,Plastic Belt Buckle, plastis base cover,Vacuum Cleaner Connection, Rail Connection,Traffice Guidepost Cap, Plunger Guide Cap,Instrument Frame,Plastic Leg,Machine support insert,Connection Box,Industrial Container



7. Medical injection mold

Rapid Cap for Insulin Pen,Sleep Posture Belt,Len Case,Dental deill cover,Orthotic foot cushions,Artificial nipples
